Glass staircase guardrail MV300

The MV300 guardrail is an innovative solution for securing outdoor areas such as terraces and pool surrounds. Designed by Made-in-glass®, this glass railing combines aesthetics and safety in an exceptional way.

MV300 Glass Railing Pack

All-inclusive package includes glass and clamp. The glass used is clear, tempered, laminated and 88/4 drilled, which means it is 17.52mm thick. The clamp used to hold the glass is sturdy and 20cm high. For each glass panel up to 120cm wide, we supply two clamps. The round clamp is fixed with three screws, while the square clamp is fixed with four screws.

The glass is drilled, which increases safety as it is held in place by clamping and locking, and the clamp screw passes through the glass. The final height of the barrier is at least 110cm, which means that the glass measures 104cm. We cut the glass panels according to your sections, leaving at least 1cm between each glass panel. The average panel width is 100cm.

Handrails are an additional option. Although not mandatory, it is recommended for outdoor use, as it protects the upper part of the glass and ensures perfect panel alignment. Last but not least, we can integrate a wicket door to hold the glass panels in place.

The MV300 Exterior Glass Guardrail Clamp

The MV300 exterior glass railing clamp plays a crucial role in the installation of glass railings in various architectural projects. Part of the MV300 series, this clamp is specifically designed for floor mounting. It is renowned for its aesthetics, durability and innovation, making the MV300 exterior glass railing a valuable addition to your projects.

The railing makes its mark in high-end architectural design with its perfection of detail. It can be installed in a variety of contexts, offering exceptional flexibility and adaptability.

The aluminum clamps used in the MV300 system guarantee a solid connection between the floor and the glass balustrade. They are robust and durable, ensuring maximum stability and safety for the balustrade. As a result, the MV300 system offers not only attractive aesthetics, but also a reliable and durable glass balustrade solution.

Other features of the MV300 series

With the Elegant Series MV300, which uses special end caps, we have the opportunity to create an exceptional glass railing that stands out for its aesthetics, simplicity and economy. It is particularly suitable for use around swimming pools, for outdoor partitions and in garden areas.

The MV300 system offers a number of advantages. It's quick to work with and easy to install, so you can complete an aesthetically pleasing project in no time.

The railing profile is very sturdy and consists of several 200cm rails. The material used here is laminated tempered glass, which has undergone standard-compliant validation tests, backed up by a test justification report. The final height of the guardrail will be determined according to your specific needs.
